Single Core Thin Wall Cable - 10.0mm˛ 70A

  (10 Reviews)
Price:  £3.56   (£2.97 Exc. VAT)

Product code:  P01301
Brand:  AMC
Cable Size  10mm˛




For cable ' By the metre' please enter the number of metres required in the qty box and this will be supplied as a continuous length.

10.0mm² high temperature thin wall cable ideal for low voltage automotive and marine applications.

This type of cable is used as standard by OEM manufacturers throughout Europe due to its high performance characteristics and properties. The Thin Wall insulation provides significant weight and volume savings, particularly in large wiring harnesses, and it has good resistance to fuels (petrol & diesel), oils, dilute acids and moisture. The hard grade insulation also provides good protection against abrasion damage and cut-through.

  • Manufactured to: ISO 6722:2006 (Class B)
  • Voltage rating: suitable for 12V & 24V systems (60V max.)
  • Nominal current rating: 70A
  • Maximum loading: 840@12V,  1680W@24V
  • No./size of conductors: 80/0.40mm
  • Conductor cross section: 10.0mm²
  • Maximum overall cable diameter: 6.0mm
  • Resistance per m at 20°C: 0.00182 Ω
  • Conductor material: Plain copper
  • Insulation material: PVC (hard grade)
  • Working temperature range: -40°C to +105°C  (with brief excursions up to +120°C )

Part Number:  TW10B.100
