Single Core Thin Wall Cable - 0.5mm² 11A

View Video

Single Core Thin Wall Cable - 0.5mm² 11A

(23 Reviews)

Price: £0.33 (£0.28 Exc. VAT)

Product code: P00628

Colour:
Length:

For cable ' By the metre' please enter the number of metres required in the qty box and this will be supplied as a continuous length.

You might also be interested in...:

Automatic Wire strippers - Max. Cable 6.0mm²

+ £16.82

Description
Specifications
Downloads / Links
Customer Reviews 23

0.5mm² high temperature thin wall cable suitable for low voltage auto and marine applications.

This type of cable is used as standard by OEM manufacturers throughout Europe due to its high performance characteristics. The Thin Wall insulation provides significant weight and volume savings, particularly in large wiring harnesses, and it has good resistance to fuels (petrol & diesel), oils, dilute acids and moisture. The hard grade insulation also provides good protection against abrasion damage and cut-through.

Manufactured to: ISO 6722:2006 (Class B)
Voltage rating: suitable for 12V & 24V systems (60V max.)
Nominal current rating: 11A
Maximum loading: 132W@12V, 264W@24V
No./size of conductors: 16/0.20mm
Conductor cross section: 0.5mm²
Maximum overall cable diameter: 1.7mm
Resistance per m at 20°C: 0.0371 Ω
Conductor material: Plain copper
Insulation material: PVC (hard grade)
Working temperature range: -40°C to +105°C (with brief excursions up to +120°C)

Part Number: TW.5B

Guide to selecting cable

Average Rating (23 Reviews):

Write a Review and share your opinions!

Rating:

Single Core Thin Wall Cable - 0.5mm² 11A

Tuesday, 15 June 2021 | Edward

Spot on

Rating:

12 Volt planet

Monday, 19 October 2020 | Howard

For all your automotive rewire or new loom needs. Wouldn't go anywhere else.

Rating:

Good product, good service

Wednesday, 14 October 2020 | Gerry

I purchased 4 different cables in combination of Red and Black. All used and very pleased with results. Would happily use again.

Rating:

16/02 stranded cable

Friday, 26 June 2020 | Eve

This cable is ideal for many model railway power supply purposes

Rating:

16/02 stranded cable

Friday, 26 June 2020 | Eve

This cable is ideal for many model railway power supply purposes

Rating:

Flexible

Wednesday, 20 May 2020 | James

Used this and another 11 different colours to rewire my fishing trolley It was perfect.

Rating:

Will use again....

Friday, 8 May 2020 | David

A quality product at a good price and delivered quickly. I will certainly use '12v Planet' again.

Rating:

My mistake

Thursday, 5 July 2018 | Jim

I found the diameter to be much more than expected. I was prepared fir a max. O.D. of 1.5mm but was disappointed to get something much more. I probably to not understand the nomenclature properly.

Rating:

red single core 0.5

Thursday, 18 May 2017 | Stephen

quick to deliver

Rating:

Easy and Fast!

Tuesday, 18 April 2017 | Mark

Web site was easy to use and I found exactly what I needed very quickly. I will definitely purchase again. Thanks.

Read all 23 customer reviews...
