Battery Isolator Switch - Removable Key

Price:  £9.00(£7.50 Exc. VAT)

Product code:  P00614

Availability:

In stock

In stock

  (11 Reviews)

Description

Battery isolator/master switch with a removable key for cars, boats and other vehicles.

Useful for preventing battery drain if left for long periods, for isolating the power source in an emergency, or as an anti-theft device.

Fitted with a splash-proof cover to protect the keyhole when the key is removed (spare key available).

Sold individually. Fixings not included.

Specification

  • Nominal operating voltage: 12V/24V
  • Max. continuous operating current: 100A
  • Max. peak current: 500A for 5secs
  • Ingress Protection (IP) rating: IP43 (solid objects >1mm and spraying water)
  • Operating temp: –40°C to +50°C
  • Terminal contact material: Copper
  • Nut material: Zinc-plated steel
  • Terminal stud size: M8 x 13mm
  • Panel hole size for barrel clearance: 23mm
  • Fixing hole dia: 6.6mm
  • Fixing hole pitch: 38mm
  • Overall height (inc. key): 106mm
  • Diameter of body: 58mm

Note: If this switch is used to isolate the vehicle's starter battery it should not be operated when the engine is running (except in an emergency situation) because there is a high risk of damage to the alternator and other parts of the vehicle's electrical system.

Further information

  • Spare key available - P01262
  • For cable size up to 16mm2, use with push on rubber terminal covers P00852
  • For cable size over 16mm2, use with push on PVC terminal covers P00848
